Gielight GL-CP3 LED Garage & Canopy Light 200W
Product Number:GL-CP3-200W-H-5000K
Fixed 200W die-cast canopy light on a 400mm square body — a different and much larger housing from the 100W above, not a bigger version of it.
- Fixed 200W output
- UL and DLC listed
- 0-10V dimmable driver
- Corrosion-resistant powder coat
- Retrofits to a 4-inch round deck opening
- 5-year limited warranty
Specifications
Wattage
200 W
Lumens
28,000 lm
Efficacy
up to 140 lm/W
Colour temperature
5000K
Voltage
120–277V
Dimming
15.75" x 15.75" x 3.31" (400 x 400 x 84mm)
Warranty
5-year limited warranty
CRI
Ra > 80
Power factor
> 0.9
Operating temp
-20°C to 50°C
Dimensions
400 x 400 x 84mm
Efficacy conflict
The spec sheet prints 150 lm/W; the price list says 140 lm/W. The lower figure is published here.
Not printed
The 200W canopy sheet prints no THD figure and no rated life, and carries no FCC badge — unlike the 100W sheet.
CCT
The sheet offers 4000/5000/5700/6500K; only 5000K is stocked.
Lumens
calculated from rated efficacy
Construction
- Die-cast aluminium, 400 x 400 x 84mm
- Corrosion-resistant powder coating
- Suits indoor and outdoor environments
Electrical
- Input 120-277VAC
- PF > 0.9
- 0-10V dimmable driver
- Fixed 200W output
Installation
- Aligns to a 4-inch round hole in the canopy deck
- Four ST 4.8 self-drilling screws to the cover panel
- Waterproof glue between cover panel and deck
- Motion sensor or emergency battery can be added
- Operating range -20°C to 50°C
Ideal applications
- Petrol station canopies
- CNG fuelling stations
- Soffits
- Parking garages
- Drive-throughs
Downloads
Spec sheet (PDF) — Gielight-200W-LED-Garage-Canopy-Light.pdf
