Gielight GL-CP3 LED Garage & Canopy Light 40-100W, Brown
Product Number:GL-CP3-100W-H-5000K (Brown)
Compatible accessories
Sensors, mounts, drivers and controls that fit this fixture.
Die-cast canopy light in brown, four selectable wattages and three selectable CCTs. Wet-location rated but for use under covered ceilings only.
- 4 selectable wattages, 3 selectable CCTs
- UL Listed under file E503399
- Wet location, covered ceilings only
- Rated life > 54,000 hours
- Microwave sensing option
- 5-year limited warranty
Specifications
Wattage
40 / 60 / 80 / 100 W
Lumens
5,600 – 14,000 lm
Efficacy
up to 140 lm/W
Colour temperature
3000K / 4000K / 5000K
Voltage
120–277V
Dimming
10-1/16" x 10-1/16" x 3-1/32" (255.46 x 255.46 x 77.1mm)
Warranty
5-year limited warranty
CRI
Ra ≥ 80
Power factor
> 0.9
THD
< 20% at full load
Rated life
> 54,000 hours
Operating temp
-30°C to 40°C
Dimensions
255.46 x 255.46 x 77.1mm
Mounting
For use under covered ceilings only — this is not an open-sky fixture despite the wet-location rating.
Lumens
calculated from rated efficacy
Sensor jack
This fixture takes 3.5mm-jack sensor heads. Only 3.5mm parts are offered here — a 2.5mm head will not seat in this base. The size comes from the models this fixture's own spec sheet names.
Construction
- Die-cast aluminium housing
- Polyester powder-coat finish for corrosion protection
- High-transmittance PC lens
- 255.46 x 255.46 x 77.1mm
Electrical
- Universal 120V through 277V operation
- PF > 0.9
- THD < 20% at full load
- 0-10V dimming
- Power tunable 40/60/80/100W, CCT tunable 3000/4000/5000K
Installation
- For use under covered ceilings only
- Microwave motion sensor can be added
- Operating range -30°C to 40°C
Ideal applications
- Petrol station canopies
- CNG fuelling stations
- Soffits
- Parking garages
- Drive-throughs
- Entryways
Downloads
Spec sheet (PDF) — Gielight-100W-LED-Garage-Canopy-Light.pdf
