EDIPAI Magnetic Light
- ETL Listed
- DLC Listed
- 5 Year Warranty
Automatic volume discount on your product total (freight not included)
- $500 to $1,9995%
- $2,000 to $3,9996%
- $4,000 to $5,9997%
- $6,000 to $7,9998%
- $8,000 to $9,9999%
- $10,000 to $19,99910%
- $20,000 to $49,99912%
- $50,000+15%
Counts every product in your cart, any brand. Applied on your quote and invoice. No minimum order.
This item is priced on quote. Add any priced item to your quote and mention this part in the notes, or contact us and we will price it for you.
Key specifications
| Manufacturer | EDIPAI |
|---|---|
| Model / part number | EDI-MR4FT18W1b-XXK G4 |
| Fixture type | Specialty |
| Family | Magnetic Light |
| Color temperature (CCT) | 3000K, 3500K, 4000K, 5000K, 6500K |
| Input voltage | 120-277V |
| Certifications | ETL, DLC |
| Warranty | 5 year minimum manufacturer warranty |
| Shipping | Ships from the manufacturer's warehouse. Freight quoted to your address before you pay. How ordering works |
EDI-MR4FT18W1b-XXK G4
- Emergency battery option
- 5 selectable power levels
- Field-selectable CCT
Specifications
LED
- LED’s available in 3000K/3500K/4000K/5000K/6500K,CRI>80
- 1CC/3CCT/6CCT Adjustable options
Electrical
- 3 Power / 5 Power Adjustable. 2FT 24" x 0.86" x 0.77"
- Driver: External max 4-channel driver, magnetic quick installation. 3FT 36" x 0.86" x 0.77"
- Input: 120-277V, 120-347V, 60Hz, PF>0.9, THD<20% 4FT 48" x 0.86" x 0.77"
- Operating Temperature Range: -4˚F - + 104˚F)
- 12V DC 200ma Options
Construction
- House: The default material is 6063 aluminum, Excellent heat dissipation, high hardness, Nano material of House options
Optics
- Lens: UL-94V0 polycarbonate material, transparent/milky options
Emergency
- Optional 120-277V/347V integral emergency battery pack available in 8W or 15W APPLICATIONS
- 90-minute backup period for code compliance • Test switch with • Offices & Commercial • Buildings laser pointer allows safe testing from floor • Retail Settings • Hotels
Downloads
Spec sheet (PDF) — EDIPAI-Magnetic-Strip-Retrofit-Kits-G4-MAY-01-2024.pdf
Questions about this fixture
What wattage, color temperature and voltage options does it have?
Wattage: 18 W. Color temperature: 3000K, 3500K, 4000K, 5000K, 6500K. Voltage: 120-277V.
Does it come with a sensor or controls?
It ships without built in controls.
What certifications does it have?
Listed by the manufacturer as: ETL, DLC. Confirm the current listing on the DLC Qualified Products List before filing a rebate.
What is the warranty?
Every fixture we carry has at least a 5 year manufacturer warranty. See the spec sheet for this model's exact terms.
Is there a spec sheet?
Yes. The manufacturer's spec sheet is a PDF you can open here. Open the spec sheet (PDF)
Is there a minimum order, and how does shipping work?
No minimum order. Larger orders get an automatic volume discount on the product total. Freight is quoted before you pay. Text 845-681-2684 with your ZIP for a quick quote.
